Prinoth BISON - Technical Data; Vehicle Dimensions

Technical data
Vehicle dimensions
4 0 3 5
1 9 6 0
3 0 0 8
8 6 3
2 4 4 0
3 6 8
8 5 1 0
5 8 3 5
4 6 0 0
5 7 3 6
1 6 6
5 3 5 0
6 2 0 0
2 4 4 0
4 2 1 6
9 6
2 2 6
1 8 1
2 3 0
3 3 5
2 1 1
2 4 4
9 6
1 4 . 5
3 4
1 1 8 . 5
1 5 9
7 7
Figure 114: BISON dimensions
Dimensions are indicated in millimeter and in inches underneath.
Vehicle data
BISON
Vehicle data
■ Dimensions
Vehicle length without : push frame, rear lift frame,
blade and tiller
4035 mm (159 in)
Vehicle length with attachments 8510 mm (335 in)
Vehicle width without tracks 2440 mm (96 in)
Vehicle width with tracks 4216mm (166 in)
Max. vehicle height 3008 mm (118.5 in)
Min. clearance above ground (ground clearance) 368 mm (14.5 in)
■ Recommended garage dimensions for maintenance work
Length 11000 mm (433 in)
Width 8000 mm (315 in)
Snow groomer BISON
Operating and Maintenance Manual
BISON 908930245 - 30367
13 - Technical data
197 (255)
