10. Reject change
Indicators and controls on the display
Figure 32: Main display
Pos. Name Image Description
1 Engine tachometer The tachometer displays the engine rpm when the engine is run-
ning:
■
Lowest idle speed: 800/min
■ Highest permissible speed: 2000/min
2 Fuel Level Indicates the fuel level; additional indicator lamp indicates when
fuel reserve level is reached
3 AdBlue/DEF level Display of the AdBlue/DEF level
4 Vehicle working hours The operating hours counter starts when the engine is running
and
as a result also counts the time required for engine preheat-
ing and the waiting times with the engine running. The indicated
number of working hours are essential for maintenance.
5 Date Indicates the current date
Snow groomer BISON
Operating and Maintenance Manual
BISON 908930245 - 30367
6 - Display
77 (255)
6.4
