3. Lower the front blade and rear tiller to the ground.
4. Switch off engine.
5. Tilt the driver's cab forward.
6. Secure the driver's cab with the safety strut.
7. Disconnect the quick-connect couplings and electrical plug connections.
8. Close quick-connect couplings tight: to do this, use the protective caps stored in the tool com-
partment.
9. Attach belt straps to the eyelets on the AUTOMATIC winch frame.
10. Pre-tension the belt straps and take care that the AUTOMATIC winch is raised from the snow
groomer in a vertical line. If necessary, move the hoisting gear.
11. Turn locking lever (4) downwards: AUTOMATIC winch unlocked (6).
12. Unscrew the rear bolts (3) that fasten the AUTOMATIC winch to the snow groomer frame and
put them aside.
13. Unscrew the bolts (9) that fasten the hydraulic cylinder (8).
14. Slowly raise the AUTOMATIC winch, taking care to prevent any damage to the driver's cab,
hydraulic hoses, loading platform and electrical system.
15. As soon as the AUTOMATIC winch has been lifted off, drive the snow groomer forwards or
move the hoisting gear away.
16. Check the hydraulic hoses and bolt fittings for leaktightness; correct any oil leaks immediately.
17. Remove the driver's cab safety strut (10).
18. Lower and lock driver's cab.
19. Attach the center cover panel to the load floor and middle engine cover.
Storing the winch
NOTICE
Risk of damage to the hydraulic system
Strong
solar radiation can cause the hydraulic fluid to heat up and by that damage the hydraulic sys-
tem.
Even the smallest particles of dirt or impurities getting into the oil can result in damage to the hydraul-
ic system.
► Do not expose the AUTOMATIC winch to direct sunlight while detached from the snow groomer.
► If solar radiation cannot be avoided, drain the oil from the return line.
► AUTOMATIC winch not mounted: cover the quick-connect couplings with clean protective caps.
■ Store the AUTOMATIC winch in a dry and well-ventilated room with a roof, where it is not in
direct contact with the ground.
■ To protect the AUTOMATIC winch, cover it with an air-permeable tarpaulin.
Snow groomer BISON
Operating and Maintenance Manual
BISON 908930245 - 30367
15 - AUTOMATIC Winch
223 (255)
