■ Rear tiller ON/OFF control (push-button
S8)
NOTE: The tiller must be activated prior to
this.
□
Rear tiller shaft OFF: To stop the rear
tiller shaft, press push-button once.
□ Rear tiller shaft ON: To activate the
rear tiller shaft, press push-button
once.
■ Rear tiller up and go: To automatically
raise, center and turn off the rear tiller,
double-click button S8.
■ Tiller Depth Control (push-button S1 and
button T)
□
Decrease tiller cutting depth: Press
and hold the S1 button then move the
T switch to the left.
□ Increase tiller cutting depth: Press
and hold the S1 button then move the
T switch to the right.
■ Tiller’s Chamber Opening Control (push-
button S1 and button T, on Posiflex only -
not available on the POWER tiller)
□
Open chamber: Press and hold the
S1 button then move the T switch
backwards.
□ Close chamber: Press and hold the
S1 button then move the T switch for-
wards.
Adjusting the outside mirror
Both outside mirrors can be adjusted on the operating console via the switch.
■ Select the desired outside mirror by turn-
ing the rotary button: to the left (2) = left
door mirror / to the right (3) = right door
mirror / neutral (1) = no mirror selected.
Operating and Maintenance Manual
Snow groomer BISON
64 (255)
5 - Vehicle
BISON 908930245 - 30367
5.9.6
