Prinoth BISON - Operation of the AUTOMATIC Winch

NOTICE
Risk of injury
►
Only hold the cable by the anchoring hook when pulling the cable manually.
Operation of the AUTOMATIC winch
NOTICE
Risk of collision
When the winch arm is swivelled, it can collide with the attachments.
►
Do not swivel the winch arm when the attachments are fully raised or turned.
NOTICE
► It is possible to assign the cable traction force function directly on the mini-joystick T without
pressing push-button S3. Go to menu item C.40 and switch the joystick button assignment.
Figure 125: Joystick
Pos. Name
1 Mini-joystick T
2 Push-button S3
Winch arm
■
The AUTOMATIC winch's arm can only be swivelled when winch operation is switched off.
Figure 126: Functions with operation of push-button S3 and mini-joystick T
Snow groomer BISON
Operating and Maintenance Manual
BISON 908930245 - 30367
15 - AUTOMATIC Winch
227 (255)
15.7.3
