Tilting the rear cover
CAUTION
Risk of crushing
if the cover is accidentally lowered
►
Keep hands clear.
► Only move the snow groomer with the cover lowered.
► There should be no people or objects on the cover if it is tilted or lowered.
It is possible to check the hydraulic oil level without lifting the cover. To do so, use the cavity (2) locat-
ed in front of the sightglass of the oil tank.
To tilt the cover and access the components, proceed as follows:
1. Remove all objects from the cover.
2. Lower the rear attachment to the ground.
3. Using the upper cavity (1), raise or lower
the cover. The cylinder will keep it in the
chosen position.
Snow groomer BISON
Operating and Maintenance Manual
BISON 908930245 - 30367
5 - Vehicle
43 (255)
5.2.3
