Prinoth BISON - Change the Winch Gear Oil

Change the winch gear oil
NOTICE
Risk of damage to the engine and gearbox
Even the smallest particles can cause damage and premature wear to the engine and transmission.
►
Ensure the utmost cleanliness when handling operating fluids.
► Check for correct filling level.
NOTICE
Risk of gear damage
Use of a lower grade or incorrect oil type can cause damage to the transmission.
►
Only use the specified oil type
➽
See "Operating fluids" (p. 238)
►
Adhere to maintenance intervals
➽
See "AUTOMATIC winch maintenance schedule" (p. 236)
NOTICE
Risk of contamination of drinking water
Operating fluids (oil, fuel, coolant, etc.) are water contaminating materials.
►
Operating fluids, and components which come into contact with operating fluids, e.g. filters or
sealing rings, should be disposed of in accordance with the environmental regulations.
► Follow the legal provisions applicable to the place of operation
NOTICE
► Only change the oil when at operating temperature.
► The winch gear must be shut down for at least 10 min so that the oil can set.
► Always use the oil level screw to check the oil level.
► Only drain the oil using the oil drain plug.
Figure 135: Winch gear
Pos. Name
1 Oil filler screw
2 Oil level screw
3 Oil drain screw
Operating and Maintenance Manual
Snow groomer BISON
244
(255)
15 - AUTOMATIC Winch
BISON 908930245 - 30367
15.8.10
