NOTICE
Risk of gear damage
Use of a lower grade or incorrect oil type can cause damage to the transmission.
►
Only use the specified oil type
➽
See "Operating fluids" (p. 238)
►
Adhere to maintenance intervals
➽
See "AUTOMATIC winch maintenance schedule" (p. 236)
NOTICE
Risk of contamination of drinking water
Operating fluids (oil, fuel, coolant, etc.) are water contaminating materials.
►
Operating fluids, and components which come into contact with operating fluids, e.g. filters or
sealing rings, should be disposed of in accordance with the environmental regulations.
► Follow the legal provisions applicable to the place of operation
NOTICE
► Only check the oil level if the vehicle is standing on level ground.
►
The winch gear must be shut down for at least 10 min so that the oil can set.
► Always use the oil level screw to check the oil level.
Figure 134: Winch gear
Pos. Name
1 Oil filler screw
2 Oil level screw
1. Park the vehicle on a level surface at operating temperature.
2. Wait at least 10 min before measurement so that the oil can set.
3. Clean the surroundings of the oil filler screw (1) and oil level screw (2).
4. Remove oil level screw (2).
5. The oil level must reach the threaded hole in the oil level screw (2), but must never be above
it.
6. If necessary, top up the level using the specified gear oil, via the oil fill screw (1) or the winch
cooling pump.
➽
See "Change the winch gear oil" (p. 244)
7. Insert the oil level screw (2) and oil fill screw (1) again.
8. Check that all screws are firmly seated.
Snow groomer BISON
Operating and Maintenance Manual
BISON 908930245 - 30367
15 - AUTOMATIC Winch
243 (255)
