8. Once the winch is tilted, install the safety
rod (5) to secure the winch. Compress the
safety rod spring to unlock the device from
its bracket (6).
9. Fold down the safety rod (5) towards the
hydraulic cylinder.
10. Insert the free end of the safety rod into
the bracket (8).
Lower the AUTOMATIC winch
CAUTION
Risk of tipping
An unlocked AUTOMATIC winch may tilt back during travel.
►
Check the locking device after lowering the AUTOMATIC winch.
► Only move the snow groomer with the AUTOMATIC winch secured.
Operating and Maintenance Manual
Snow groomer BISON
214
(255)
15 - AUTOMATIC Winch
BISON 908930245 - 30367
■
