CAUTION
Risk of accident
Adjusting the driver seat while driving can lead to accidents.
►
Do not adjust the driver seat while driving the vehicle.
► Only adjust the driver seat when the vehicle is stopped.
Figure 9: Swivel seat
Pos. Name Description
1 Seat rotation lev-
er
To swivel the seat.
■ Push
the seat rotation lever to the left and hold it. Then, swivel the
seat manually and release the lever in the required position. The seat
can be swivelled into three different positions.
2 Locking screw To lock the seat when sliding the seat manually.
3 Threaded hole To place the locking screw and lock it when sliding the seat manually.
■ To move the seat sideways, press the up-
per (4) or lower part (5) of the rocker
switch on the control console. As soon as
the rocker switch is released, the electric
motor will stop and the seat will remain in
its position.
Operating and Maintenance Manual
Snow groomer BISON
46 (255)
5 - Vehicle
BISON 908930245 - 30367
