Beta Draft Confidential
Control Page
Internet Managed Thermostat Configuration Guide, Release 1.0 2-9
Part No. 600-03001-550, Rev. 1
Usage Statistics
The Control - Usage Statistics page displays the usage information.
Figure 2-7 Control - Usage Statistics Page
Use Table 2-3 to configure the Control - Usage Statistics fields.
Table 2-3 Control - Usage Statistics Field Descriptions
Output Polarity
Closed - Normally closed output.
Open - Normally open output.
Include Relay in
OBO
Displays when OBO is activated if the associated relays using this function
are to be activated as well.
Disabled
Enabled
Field Description
Field
Description
Usage Counters
Heating Displays thee Heat1 and Heat 2 relay minute activity counter. The Admin
account user can reset this field by checking the Last counter reset box.
Fan/Filter Displays the Fan/Filter relay minute activity counter, which is the number
of days, hours, and minutes since the Last counter reset box was checked
and submitted. The Admin account user can reset this field by checking the
Last counter reset box.
