CHAPTER 2: Configuring the Thermostat Using the Web Interface
Use Table 2-10 to configure the Override Settings fields.
Table 2-10 Advanced - Override Settings Field Descriptions
Field Description
Hold
Allow Hold Indicates if thermostat temperature setting are held independent
of schedule changes due to Event or Daily Profiles
advancements.
 Enabled - Allow the temperature settings to be held for the
duration shown below.
 Disabled - Do not allow the temperature settings to be held.
Hold Mode Duration Specifies the time interval in which the thermostat temperature
setting are held independent of schedule changes due to Event or
Daily Profile advancements.
 Perm – The Hold period is indefinite and the temperature
setting are “held” until the user removes this condition.
 1, 2, 3, 8, 12, 24 Hrs –The amount of time in hours in which
the current temperature setting are “held” and inhibited from
change. The default interval is 3 Hrs.
Note: These durations are observed across Event boundaries.
General Occupancy Override Settings
Cool Setting Displays the cool setpoint to be used while One Button Override
(OBO) is active.
40
°
F(4.5
°
C) to 110
°
F(43.5
°
C)
Heat Setting Displays the current temperature programmed for the heating
system.
40
°
F(4.5
°
C) to 110
°
F(43.5
°
C)
Fan Schedule Specifies the time in minutes of each hour of the Event in which
the fan will be On. The schedule begins on the hour and
advances for the duration specified. Note that within the hour of
each Event but outside the schedule interval, the fan behaves the
same as AUTO mode to ensure proper operation for either a
heating or cooling call to the HVAC system. Select one of the
following options:
 Always Off
 5 On / 15 Off
 10 On / 10 Off
 15 On / 5 Off
 Always On
