CHAPTER 2: Configuring the Thermostat Using the Web Interface
Morning (for example, pre-business hours)
Day (for example, business hours)
Evening (for example, after hours)
Night (for example, unoccupied hours)
Figure 2-8 on page 2-11 displays the Profile table. The Web page displays the Event
period and Start Time within each row of the table. The Web page also displays the
heat and cool settings for each Event period in each Profile. Although the thermostat
ships from the factory with pre-set Event settings, you can change these settings by
selecting the appropriate definition from the drop-down menu.
Use Table 2-4 to configure the Daily Profile Definitions.
Table 2-4 Schedules-Daily Profile Definitions Field Descriptions
Field Description
Daily Profile Definitions
Profile Name Use the drop-down menu to select the appropriate profile. The profile name
displays in the header. Click Color and select a color to color-code the profile for
easy recognition.
Event Displays one of four time periods of the 24-hour day.
Start Time Use the drop-down menu to modify the time period in 5-minute increments.
Includes AM/PM indicator.
Heat Use the drop-down menu to select a heat temperature setback setting between
40
°
F(4.5
°
C) to 110
°
F(43.5
°
C)
Cool Use the drop-down menu to select a cool temperature setback setting between
40
°
F(4.5
°
C) to 110
°
F(43.5
°
C)
Fan Schedule Select the time in minutes for each hour of the Event in which the fan will be On.
The schedule begins on the hour and advances for the duration specified. Note that
within the hour of each Event but outside the schedule interval, the fan reverts to
AUTO mode to ensure proper operation for either a heating or cooling call to the
HVAC system. Select one of the following options:
Always Off
5 On / 15 Off
10 On / 10 Off
15 On / 5 Off
Always On
