2-26 Internet Managed Thermostat Configuration Guide, Release 1.0
Part No. 600-03001-550, Rev. 1
CHAPTER 2: Configuring the Thermostat Using the Web Interface
Remote Sensor 1, 2, and 3
Sensor Name Displays the Name (15 characters) for the external thermal
sensor #1/#2/#3.
RS1 / RS2 / RS3
The default is RS1, RS2, RS3.
Type Select the remote sensor type: thermistor or contact to determine
whether or not a temperature sensor or dry contact closure
source is connected to this sensor. (Consult the Proliphix web
site for a list of sensors available in either type.)
Thermistor – Thermistor-based thermal sensors.
Contact – Contact-based connections.
The Contact closure option can be used to sense if a door is
open or closed for greater than the number of minutes set on
the Alarms page and then notify you via an alert e-mail. For
example, this option is often used in food service
applications but can be used for any situation where you
need to monitor a Contact closure.
Unconfigured (default)
Motion Sensor
State
Group Specifies if the sensor is assigned to Indoor Temp or Outdoor
Temp.
Note: If one ore more of the remote sensors are configured as
witin the Outdoor Temp group, only the first (that is, RS1 then
RS2 then RS3, in that order) are displayed on the thermsotat’s
LCD screen.
Current Reading Displays the current local temperature.
Sensor Correction Indicate the calibration or temperature offset compensation for
this remote thermal sensor. Offset adjustments are added or
subtracted from the actual temperature read from this sensor and
displayed as the apparent temperature.
-10
°
F (-5.5
°
C) through +10
°
F (5.5C)
The default is 0.
Table 2-7 Sensors Field Descriptions (Continued)
Field Description
