Electrical power cable
Your trailer is equipped with a power cable to
connect to an external 120-volt electrical
outlet (source) with 15 or 30 amps. You must
not alter or cut the cablefor any reason, nor
remove components from the connector
(plug). If you must use an adaptor to connect,
ensure that all three prongs are fully inserted
into the adaptor.
ELECTRICAL SYSTEM
When you connect the power cable to the electrical outlet (e.g. electrical terminal in a
campground), press the connector (plug) fully into place for a proper installation.
To connect your trailer
1. Insert the cable connector (plug) into the electrical source outlet at the site.
2. Check that the source breakers are in the ‘‘ON’’ position.
3. If there is no power, check that the trailer’s main breakers are in the ‘‘ON’’ position.
To disconnect
1. Remove the cable connector (plug) from the electrical source.
2. Stow the power cable.
