ProMinent DULCO flex Control Original Operating Instructions

4
Supplementary Operating Instructions for PROFINET
®
4.1 Requirements............................................................. 61
4.2 Adjusting the pump..................................................... 61
4.2.1 General.................................................................... 61
4.2.2
Activating / deactivating PROFINET
®
......................
61
4.2.3
Configuring PROFINET
®
.........................................
62
4.3
Special features in active PROFINET
®
mode.............
63
4.3.1 General.................................................................... 63
4.3.2 Displays................................................................... 63
4.3.3
LEDs on the PROFINET
®
module........................... 64
4.3.4 Using the metering monitor...................................... 64
4.4 Installation................................................................... 65
4.5 Operation.................................................................... 65
4.5.1 General.................................................................... 65
4.5.2 GSDML file.............................................................. 65
4.5.3 DULCO flex Control DFXa, DFXa data objects....... 66
4.5.4 Diagnostic messages and types of data access...... 74
4.5.5 PLC error and pump behaviour............................... 75
4.1 Requirements
Personnel must be familiar with the contents of the "Peristaltic
metering pump DULCO flex Control, DFXa"!
The pump must have the identity code feature "Control type": "E" -
"PROFINET 10". The ‘Fieldbus’ menu item is then available in the
operating menu. (When
‘Fieldbus è Active’ is set, ‘Settings
è PROFINET’ also appears in the operating menu.)
4.2 Adjusting the pump
4.2.1 General
The pump with PROFINET
®
functionality is adjusted in the same
way as the standard pump, with the addition of the bus function‐
ality.
The adjustment process is cancelled in the event
of a pause lasting longer than 60 s.
4.2.2
Activating / deactivating PROFINET
®
In order for the pump to be activated using the PROFINET
®
,
‘Fieldbus’ must be set to ‘Active’ in the operating menu.
1.
Press the
[Menu] key to access the ‘Menu’ .
ð
The cursor immediately goes to ‘Information’ .
2. To switch from
‘Information’ to ‘Fieldbus’ , turn the
[Clickwheel] and press it.
3. To switch from
‘Fieldbus’ to ‘Inactive / Active’ , turn the
[Clickwheel] and press it.
Supplementary Operating Instructions for PROFINET
®
61
