2.10.7 "Advanced configuration" register
These register inputs are all for function code "0x03", "0x06", 0x10
and 0x17 (Read / Write).
Register Designation Type Display / purpose
1400 Pump start behaviour Enum Configuration as to how the pump should behave
after a power-up:
0 - ALWAYS OFF
1 - ALWAYS ON
2 - STATUS IMMEDIATELY BEFORE LAST
SWITCH-OFF
1407 Analogue input "operating
mode"
Enum Setting of analogue operating mode:
0 - 0...20mA
1 - 4…20 mA
2 - 20…0mA
3 - 20…4mA
4 - LINEAR CURVE
5 - LOWER SIDE BAND
6 - UPPER SIDE BAND
1408 "Current 1st user-defined
point" analogue input
FLOAT32 For the analogue operating modes - LINEAR
CURVE - LOWER SIDE BAND - UPPER SIDE
BAND this parameter determines the current value
for the first support point of the "Current <-> stroke
rate/capacity" assignment lines
0.0 … 20.0 mA
1411 "Capacity 1st user-defined
point" analogue input
FLOAT32 For the analogue operating modes - LINEAR
CURVE - LOWER SIDE BAND - UPPER SIDE
BAND this parameter determines the metering rate
for the first support point of the "Current <->
capacity" assignment lines. Setting in Auto On oper‐
ating mode only
0 … [max. capacity] l/h
1413 "Current 2nd user-defined
point" analogue input
FLOAT32 For the analogue operating modes - LINEAR
CURVE - LOWER SIDE BAND - UPPER SIDE
BAND this parameter determines the current value
for the second support point of the "Current <->
stroke rate/capacity" assignment lines
0.0 … 20.0 mA
1416 "Capacity 2nd user-defined
point" analogue input
FLOAT32 For the analogue operating modes - LINEAR
CURVE- LOWER SIDE BAND - UPPER SIDE BAND
this parameter determines the metering rate for the
second support point of the "Current <-> capacity"
assignment lines. Setting in Auto On operating mode
only
0 … [max. capacity] l/h
1418 "Fault message current too
high" analogue input
BOO‐
LEAN
0 - DO NOT REPORT FAULT
1 - REPORT FAULT
1419 "Fault message current too
low" analogue input
BOO‐
LEAN
0 - DO NOT REPORT FAULT
1 - REPORT FAULT
Supplementary operating instructions for Modbus RTU
41
