If the metering monitor is set to
‘Active’
, it issues either a warning
or an error with DULCO flex Control DFXa.
4.4 Installation
CAUTION!
Degree of protection IP 65
– IP 65 degree of protection only applies if the
appropriate assembly accessories (cable open‐
ings etc.) have been fitted correctly.
The connection to the existing LAN infrastructure is provided by a
suitable LAN cable, e.g. twisted pair cable (CAT5 or higher) to
comply with IP 65 with a screwed M12x1 plug, 4-pin, D-coded to
IEC 61076-2-101. Complies with IEEE 802.3.
Tab. 39: Connectors
Module label Meaning
OUT Port 1
IN Port 2
Mains extension:
n Copper-based twisted pair cable (TP) maximum 100 metres.
4.5 Operation
4.5.1 General
Using the connected PROFINET
®
module, the pump in the PRO‐
FINET
®
represents a device with slave functionality. User data is
then transmitted cyclically.
4.5.2 GSDML file
Use the GSDML file to configure the master. The GSDML file
describes all the features of the pump in PROFINET
®
mode (key‐
words, diagnostics, modules, sub-modules). The GSDML file can
be downloaded from the PROFINET
®
website and from the ProMi‐
nent website. The file name is clearly indicated:
GSDML-V2.35-Prominent-DFXa-20191118.xml.
Bus installation
Supplementary Operating Instructions for PROFINET
®
65
