10.2 Setting the Relays
Relay combination
Relay 1 and relay 2 can be configured independently of each other. Thus any combi‐
nation of "Off / Limit / Actuator / SV / Timer" is possible.
Possible values
Factory setting Increment Lower value Upper
value
Remarks
Relay
assign‐
ment
As per identity
code
Solenoid
valve (SV1,
SV2)
Limit value
(limit 1/2)*
Actuator 1/2
Timer 1/2
Off
*At the limit,
the relays
remain acti‐
vated even
in the event
of a malfunc‐
tion.
Cycle 10 s 1 s 10 s 9999 s For solenoid
valve
Min. time 1 s 1 s 1 s Cycle/2 For solenoid
valves: the
smallest per‐
missible
switch-on
period of the
connected
device
should be
set here
Cycle Off 1 h 1 h/off 240 h For timer
T On 1 minute 1 minute 1 minute 240 min. For timer
