7. Insert the device from the outside in the opening, attach the retaining bracket and
push backwards up to the stop
ð
All four holes retaining brackets must be attached, as otherwise protection
rating IP54 cannot be adhered to.
8. Using a suitable screw driver, screw the studs forwards, see
Fig. 17, until the seal
is completely and uniformly compressed
9. Check the correct seating of the seal, as necessary loosen the studs and correct
the position
4.3 Electrical Installation (Con‐
trol Panel Mounted)
Connect up as per the electrical terminal
wiring diagram. Refer to
Ä Chapter 4.3.3
‘Terminal diagram ’ on page 48
D1Cc mounting
44
