OPTALIGN smart RS5 BT handbook
188
RS5 BT sensor
Type 5-axis sensor: 2 planes (4 displacement axes and angle)
Measurement area: unlimited, dynamically extendible (U.S. Patent 6,040,903)
Resolution: 1 µm (0.04 mil) and angular 10 µRad
Accuracy (avg): > 98%
Measurement rate: approx. 20 Hz
Inclinometer Resolution: 0.1°
Error: 0.3% full scale
LED indicators 1 LED for laser adjustment and battery status
1 LED for Bluetooth communication
Power supply Lithium-Ion rechargeable battery: 3.7 V / 5 Wh
Operating time: 10 hours (continuous use)
Charging time: Using charger – 2.5 h for up to 90%; 3.5 h for up to 100%
Using USB port – 3 h for up to 90%; 4 h for up to 100%
External interface Integrated Bluetooth 4.1 Smart Ready wireless communication
USB 2.0 Full Speed
Transmission distance Up to 30 m [98 ft] direct line of sight
Environmental protection IP 65 (dustproof and water jets resistant), shockproof
Relative humidity: 10% to 90%
Ambient light protection Yes
Temperature range Operation: -10°C to 50°C [14 °F to 122°F]
Storage: -20°C to 60°C [-4°F to 140°F]
Charging: 0°C to 40°C [32°F to 104°F]
Dimensions Approx. 105 x 74 x 58 mm [4 9/64” x 2 29/32” x 2 1/4”]
Weight Approx. 235 g [8 1/3 oz.]
CE conformity Refer to the CE compliance certificate in www.pruftechnik.com
RS5 laser
Type Semiconductor laser diode
Beam divergence 0.3 mrad
Beam power < 1 mW
Wavelength 630 – 680 nm (red, visible)
Safety class Class 2 according to IEC 60825-1:2007
The laser complies with 21 CFR 1040.10 and 1040.11 except for
deviations pursuant to Laser Notice No. 50, dated June 24, 2007.
Safety precautions Do not look into laser beam
Power supply Batteries 2 x 1.5 V IEC LR6 (“AA“)
Operating time: 180 hours
Environmental protection IP 65 (dustproof and water jets resistant), shockproof
Relative humidity: 10% to 90%
Temperature range Operation: -10°C to 50°C [14°F to 122°F]
Storage: -20°C to 60°C [-4°F to 140°F]
Dimensions Approx. 105 x 74 x 47 mm [4 9/64” x 2 29/32” x 1 27/32”]
Weight Approx. 225 g [7 15/16 oz.]
CE conformity Refer to the CE compliance certificate in www.pruftechnik.com
Carrying case
Standard ABS, drop tested 2 m [6 1/2 ft]
Dimensions Approx. 480 x 400 x 195 mm [18 57/64” x 15 47/64” x 7 43/64”]
Weight Including all standard parts: approx. 8.3 kg [18.3 lb.]
