PRÜFTECHNIK OPTALIGN smart RS5 BT - Table of Contents

3
Contents
Contents
Foreword ..............................................................2
Chapter 1: OPTALIGN smart RS5 BT packages .................................5
1.1 OPTALIGN smart RS5 BT package with rechargeable battery computer ALI 12.015-RS5R 5
1.2 OPTALIGN smart RS5 BT package ALI 12.015-RS5 ............................................................ 9
Chapter 2: Safety notes and operating information ...........................11
2.1 Safety notes ..................................................................................................................11
2.2 Operating information ..................................................................................................12
Chapter 3: OPTALIGN smart RS5 BT – Description .............................17
3.1 Description ...................................................................................................................17
3.2 Computer power supply ...............................................................................................18
3.3 RS5 laser and RS5 BT sensor .........................................................................................20
3.4 Mini compact chain-type bracket ALI 2.118 ..................................................................27
Chapter 4: Getting started ...............................................29
4.1 Set-up ..........................................................................................................................29
4.2 Set RS5 BT sensor as default .........................................................................................30
4.3 Enter dimensions ..........................................................................................................31
4.4 Wireless measurement .................................................................................................. 32
4.5 Results .......................................................................................................................... 35
4.6 Context menu items .....................................................................................................37
Chapter 5: Horizontal machine alignment ...................................39
5.1 Preparing for the alignment procedure .........................................................................39
5.2 Check for soft foot .......................................................................................................40
5.3 Mount the brackets .....................................................................................................40
5.4 Mount laser and RS5 BT sensor .................................................................................... 42
5.5 Switch the computer on and start application ...............................................................44
5.6 Enter machine dimensions ............................................................................................44
5.7 Machine set-up .............................................................................................................47
5.8 Flipping machines .........................................................................................................67
5.9 Laser beam adjustment ................................................................................................. 69
5.10 Take measurements ....................................................................................................74
5.11 Results ........................................................................................................................ 76
5.12 Rotating machine view ................................................................................................84
5.13 Align machine .............................................................................................................85
5.14 Saving data and printing ............................................................................................. 94
5.15 Quick check measurement .......................................................................................... 99
5.16 Soft foot ................................................................................................................... 101
