Pulse Secure Gateway MAG2600 Back Panel
The next figure shows the back panel of the MAG2600:
The retention clip provides support to hold the power cord on to the power supply point.
Pulse Secure Gateway MAG4610 Front Panel
The next figure shows the front panel of the MAG4610:
Front panel components of the MAG4610:
•
Blank faceplate
•
Console port
•
USB port
•
Ethernet ports 0, 1 and 2
•
LEDs (power, activity, alarm)
