Chassis Management Card Overview
The Pulse Secure Gateway Chassis Management Card (CMC) is an optional management module that you can
install on a MAG6610 and MAG6611. No more than one CMC is ever installed on a Pulse Secure Gateway.
The CMC runs the OS.
The CMC provides a visual representation of the Pulse Secure Gateway chassis and all installed modules. You
can view all installed modules using either the CLI or the Web interface.
Another benefit of the CMC is that it provides SSO to all modules through a single IP address and launches
that module’s administrative user interface.
Figure: Web Interface
The CMC uses a dedicated reserved slot in the MAG6610 or MAG6611 chassis. At most one CMC should be
installed per chassis.
The following lists the CMC front panel components.
•
Console
•
Ethernet ports 0 (em0) and 1 (em1) • USB port
•
LEDs (power, activity, alarm)
•
Power button
