MAG Series Pulse Secure Gateways Hardware Guide
© 2016 Pulse Secure, LLC., All rights reserved.
17
• Module removal lever
• Service module
Pulse Secure Gateway MAG6611 Back Panel
The following figure shows the back panel of a populated MAG6611:
The back panel components of the populated MAG6611 are as follows:
• Power supply
• Fan Power supply (empty) tray
• Power switch
• Hard drive
