MAG Series Pulse Secure Gateways Hardware Guide
© 2016 Pulse Secure, LLC., All rights reserved.
Requirement for Clearance
Space for service personnel to
remove and install hardware
components.
NOTE: More space is required for
installing and removing Mini-PIMs.
Space for service personnel to
remove and install hardware
components
Between the front-mounting
flange and the rack or cabinet
edge
Space for cable management and
organization.
Between the front-mounting
flange and the rack or cabinet
edge
Space for cable management and
organization.
Between the side of the chassis
and any devices that have fans or
blowers
Space for the cooling system
to function properly and for
maintaining unrestricted airflow
around the chassis.
AC Power Cord Specifications
Each AC power supply for the MAG6610 and MAG6611 Pulse Secure Gateway has a single AC appliance inlet
located on the power supply that requires a dedicated AC power feed. Most sites distribute power through
a main conduit that leads to frame-mounted power distribution panels, one of which can be located at the
top of the rack that houses the Pulse Secure Gateway. An AC power cord connects each power supply to
the power distribution panel.
Each detachable AC power cord is 2.5 m (approximately 8 ft) long. The appliance coupler at the female end
of the cord inserts into the AC appliance inlet on the faceplate of the AC power supply. The coupler type is
C13, as described by the International Electrotechnical Commission (IEC) standard 60320. The plug at the
male end of the power cord fits into the power source outlet that is standard for your geographical location.
NOTE: In North America, AC power cords must not exceed 4.5 m (approximately 15 ft) in length, to comply
with National Electrical Code (NEC) Sections 400-8 (NFPA 75, 5-2.2) and 210-52 and Canadian Electrical Code
(CEC) Section 4-010(3). The cords shipped with the Pulse Secure Gateway are in compliance.
Country-specific power cords are shipped with each device.
