© 2016 Pulse Secure, LLC., All rights reserved.
MAG Series Pulse Secure Gateways Hardware Guide
•Use a two-post rack or a four-post rack. You can
mount the Pulse Secure Gateway on any two-post
or four-post rack that provides bracket holes or
hole patterns spaced at 1-U (1.75-in. or 4.45-cm)
increments and that meets the size and strength
requirements to support the weight.
•A U is the standard rack unit defined in Cabinets,
Racks, Panels, and Associated Equipment
(document number EIA-310–D) published by the
Electronics Industry Association
(http://www.eia.org).
•The rack must meet the strength requirements to
support the weight of the chassis.
•A 19-in. (48.3-cm) rack as defined in Cabinets,
Racks, Panels, and Associated Equipment
(document number EIA-310-D) published by the
Electronics Industry Association
(http://www.eia.org).
•The outer edges of the mounting brackets extend
the width of either chassis to 19-in. (48.3-cm).
•The front of the chassis extends approximately
0.50-in. (1.27-cm) beyond the mounting ears.
•The maximum permissible ambient temperature
when two devices are placed side by side in a 19-in.
rack is 104 °F or 40 °C.
Spacing of mounting bracket flange holes
•The holes within each rack set are spaced at 1-U
[1.75-in. (4.5 cm)]. The device can be mounted in
any rack that provides holes or hole patterns and
spaced at 1-U (1.75-in., or 4.5-cm) increments.
•The mounting brackets and front-mount flanges
used to attach the chassis to a rack are designed
to fasten to holes spaced at rack distances of 1-U
(1.75 in., or 4.5-cm).
•The mounting holes in the mounting brackets
provided with the device are spaced 1.25 in. (3.2
cm) apart (top and bottom mounting holes).
Connection to the building structure
•Always secure the rack in which you are installing
the services gateway to the structure of the
building. If your geographical area is subject
to earthquakes, bolt the rack to the floor. For
maximum stability, also secure the rack to ceiling
brackets.
