Pylontech M1C-UL9540 User Manual

25
2.4.3 Parameters of the Single Battery System
Product Type
PowerCube-M1-C(30kW)
PowerCube-M1-C(60kW)
Controller Type SC1000-200J-C
Battery Module Type H32148-C
Nominal Voltage (VDC) 32 × n (where n = 10~14) 32 × n (where n = 14~21)
Rated Capacity (Ah) 148 148
Total Storage Energy (kWh) 4.736 × n (where n = 10~14) 4.736 × n (where n = 14~21)
Charge Upper Voltage (VDC) 36 × n (where n = 10~14) 36 × n (where n = 14~21)
Discharge Lower Voltage (VDC) 27 × n (where n = 10~14) 27 × n (where n = 14~21)
Nominal Current (Amps) 74
Max. Continuous Current (Amps) 148
Peak Current (Amps) 220@15 seconds
Over Current/Duration (Amps/ms) 8000/2
IP Rating/Protection Class IP20/I
Operation temp. range(°C) 10 ~ 40
Communication type CANBUS/Modbus RTU/TCP/IP
Storage temp. range(°C) -20 ~ 60
Humidity (%) 5 – 95 (without condensing)
Round-trip efficiency (%, @1C-rate)
95
Depth of Discharge (%) 95
Dimensions(mm)
815(W)x 659(D)x 213(H)
Weight (kg) 114+ 43×n (where n = 10~14) 114+ 43×n (where n = 14~21)
Operation cycle life (cycle)
*
>5,000
Operation Life(year)
15+
IP rating IP20
Cooling type Natural cooling
Altitude [m]
<2,000
Certifications
UL1973, UL9540A, IEC62477-1, IEC62040-1, IEC62619, IEC63056，
UKCA，CE LVD, CE EMC, UN38.3, VDE-AR-E 2510-50
*Cycle life is defined based on specific operation conditions, for more details please check with Pylontech service team.
