Pylontech M1C-UL9540 User Manual

10
2.1.2 Parameters of 60kW system
Specifications
Model Name
Optim US-Am-M1C-A-60kW/xx
*
-US-yy
**
(14~21 batteries per one string, 1~2 strings parallel)
AC side
Parameters
Rated Power(kW) 60
Rated Output Voltage (VAC) 480
Max. output current(A) 73
Rated frequency (Hz) 60
Wiring method Three-phase four wire +PE
ON-Off Grid Switching 5ms
Photovoltaic
Parameters
Rated Power(kW) 78
Max. output current(A) 1000
Max. output current(A) 36
MPPT voltage range(V) 280-850
MPPT starting voltage(V) 180
MPPT Interface Qty. 4
DC side
Parameters
BMS Qty.
m (where m=1,2)
Battery string Qty. (same as BMS
Qty.)
m (where m=1,2)
Battery module Qty.
(=battery module Qty in one
single string x battery string Qty.)
n (where n= 14x m, 15 x m, 16 x m, 17 x m, 18 x m,
19 x m, 20 x m, or 21 x m, m=1 or 2)
(Here there can be 14, 15, 16, 17, 18, 19, 20 or 21 batteries in
one single string)
Rated Energy(kWh)
4.736 (single battery energy x n (battery module Qty.)
(where n=14,15,16,17,18,19,20,21,28,30,32,34,36,38,40,42)
Battery rated voltage(V)
See the details in the
System
Configuration List-60kW
on the
next page.
Maximum DC current (A)
100
System
Parameters
Firefighting Configuration
See the details in the
System Configuration List-60kW
on the
next page.
Cooling Type Industrial Air Conditioner(2kW)
Working Temperature range(℃)
-20~50
Storage Temperature range(℃)
-20~60
Relative Humidity 0-95%RH, non-condensing
Noise (dB) ≤65
Altitude (m) 2000
External Dimensions of Outdoor
Cabinet (mm)
1110(W) x 2185(H) x 1655(D)
Corrosion Resistance Grade
C3H (Standard Configuration)
C5(Optional)
Weight (kg)
800 x m (BMS Qty.) + 43 x n (battery module Qty.) +80 (PCS
weight)
Installation Type
Cabinet installed on the ground.
Applicable for hoist and forklift handling
IP Rating of the outdoor cabinet IP55
*“xx “represents the rated energy of the battery system, after calculation, only keeping the integer part, then you
will get the numbers as the table
System Configuration List-60kW on the next page.
**"yy" represents the firefighting configuration, referring to the table System Configuration List-60kW on the next
page.
