Pylontech M1C-UL9540 User Manual

35
3. System Installation and Operation
3.1 Outdoor battery cabinet layout
3.1.1 External Dimensions
External dimensions are the same for both the 30 kW and 60 kW systems:
- Optim US-Am-M1C-A-30kW/xx-US-yy (10 batteries per one string, 1~4 strings parallel; where m =
1, 2, 3 or 4, xx=47, 94, 142,189, yy = 01, 02, 03, 04, or 05)
- Optim US-Am-M1C-A-30kW/xx-US-yy (11~14 batteries per one string, 1~2 strings parallel; where
m = 1, or 2; xx = 52, 56, 61, 66, 104, 113, 123 or 132; yy = 01, 02, 03, 04, or 05)
- Optim US-Am-M1C-A-60kW/xx-US-yy (11~14 batteries per one string, 1~2 strings parallel; where
m=1 or 2, xx= 66, 71, 75, 80, 85, 90, 94, 99, 132, 142, 151, 161, 170, 180, 189, or 198; yy = 01, 02,
03, 04, or 05)
(Unit: mm)
Front View
Top View
Bottom View
Right Side
View
