Annex 5: Installation and System Turn ON Process List
Tick after
completion
No.
Item
Remark
☐
1
The environment is meeting all technical requirements.
3.3.1
Cleaning
3.3.2
Temperature
3.3.3
Radiating System
3.3.4
Heating System
3.3.5
Fire-extinguisher System
3.3.6
Grounding System
Refer to section
3.3
☐
2
Battery rack is installed following the technical
requirements.
Refer to
section
3.5.3.
3
Control Module (BMS) and Battery Module are installed
well.
And install the rack metal strip.
Refer to
section
3.5.4.
4
The MBMS are installed well. (If configured.)
Refer to
section
3.5.5.
5
The Ethernet Switch is installed well. (If configured.)
Refer to
section
3.5.6.
6
Connect the AC power cables from BMS, MBMS and
Ethernet
Switch to the AC “OUT PUT” socket of the UPS.
(If configured.)
Refer to
section
3.6.2.1 or 3.6.2.2.
7
Connect External Power Cable +/- between each BMS
to the INVERTER or confluence cabinet.
Refer to
section
3.6.2.1 or 3.6.2.2.
8
Connect power cables of each battery string.
Refer to
section
3.6.2.1 or 3.6.2.2.
9
Connect communication cables of each battery string.
Refer to
section
3.6.2.1 or 3.6.2.2.
10
Set up ADD switch of every BMS and the MBMS
( Address Assignment).
Refer to
section
3.6.3.
11
Connect external communication cables from BMS to
Ethernet Switch, MBMS or another.
Refer to
section
3.6.2.1 or 3.6.2.2.
13
Connect the communication cable from MBMS to the
INVERTER.
Refer to
section
3.6.2.1 or 3.6.2.2.
To Next Page
