14
Double check every power cable, communication
cables are installed well. And ADD Switches are setting
right.
Refer to
section
3.6.2.1 or 3.6.2.2
and 3.6.3.
15
Check whether the UPS is turned on. And the UPS is
power supplying.
Refer to
section
3.6.4.
16
Switch the external power or INVERTER on, be sure all
the power equipment working normally.
Refer to
section
3.6.4.
☐
17
Turn the BMS (Battery Control Modules) of each
battery
string on (from 1
st
BMS to the last, one by one)
□
Turn on the “POWER OUTPUT SWITCH”:
□
Turn on the “Power Switch”:
□
The battery string’s system will check itself if work
normal
the battery string system will go into self-
check mode.
If has failure during the self-check, be sure to debug.
the failure then can start next step.
Refer to
section
3.6.4.
18
If every battery string is working normally.
Then switch the MBMS on. The MBMS will self-check
and check each battery string one by one.
Refer to
section
3.6.4.
☐
19
The first installation should do full charging progress.
After MBMS communicating with each BMS, it will run
parallel operation. It will start up from lowest voltage
battery string to do the parallel operation during the
charging.
If the status LED of BMS turns to green, it means this
battery string is in parallel operation.
The first
installation should
do full charging
progress.
To Next Page
