Pylontech M1C-UL9540 User Manual

42
3.1.8 Cabinet Grounding
• PE (to the ground): Choose one of the four grounding points to connect the cabinet to the ground.
(Grounding Screw specification: M10 x 30)
• Grounding bar (electrical PE): Grounding cable(s) connected to grounding bar inside the cabinet.
(Grounding Screw specification: M16 x16)
Front
Back
