Pylontech M1C-UL9540 User Manual

11
System Configuration List-60kW
Item
Model
Battery
String
Qty.
Single String
Configuration
Rated
Voltage
(V)
Energy
(kWh)
XX
(Battery
Energy)
yy
(firefighting
configuration)
1
Optim US-A1-M1C-
A-60kW/ xx -US- yy
1
1 BMS + 14
battery modules
448
66.3 66
“yy" represents the
firefighting configuration:
01: Explosion relief panel
02: Explosion relief panel
+ Sprinkler system
03: Ventilation fan
04: Ventilation fan +
Sprinkler system
05: Explosion relief panel
+Ventilation fan +
Sprinkler system
2
Optim US-A2-M1C-
A-60kW/ xx -US- yy
2 132.6 132
3
Optim US-A1-M1C-
A-60kW/ xx -US- yy
1
1 BMS + 15battery
modules
480
71.0 71
4
Optim US-A2-M1C-
A-60kW/ xx -US- yy
2 142.1 142
5
Optim US-A1-M1C-
A-60kW/ xx -US- yy
1
1 BMS + 16
battery modules
512
75.8 75
6
Optim US-A2-M1C-
A-60kW/ xx -US- yy
2 151.6 151
7
Optim US-A1-M1C-
A-60kW/ xx -US- yy
1
1 BMS + 17
battery modules
544
80.5 80
8
Optim US-A2-M1C-
A-60kW/161-US- yy
2 161.0 161
9
Optim US-A1-M1C-
A-60kW/ xx -US- yy
1
1 BMS + 18
battery modules
576
85.2 85
10
Optim US-A2-M1C-
A-60kW/ xx -US- yy
2 170.5 170
11
Optim US-A1-M1C-
A-60kW/ xx -US- yy
1
1 BMS + 19
battery modules
608
90.0 90
12
Optim US-A2-M1C-
A-60kW/ xx -US- yy
2 180.0 180
13
Optim US-A1-M1C-
A-60kW/ xx -US- yy
1
1 BMS + 20
battery modules
640
84.7 94
14
Optim US-A2-M1C-
A-60kW/ xx -US- yy
2 189.4 189
15
Optim US-A1-M1C-
A-60kW/ xx -US- yy
1
1 BMS + 21
battery modules
672
99.5 99
16
Optim US-A2-M1C-
A-60kW/ xx -US- yy
2 198.9 198
