980 DP Video Generator - User Guide Rev. A4
Page 146 July 14, 2014
Field / Entity
Entity Name
Description / Function
component.
B
Puts the analog composite sync on the Blue component.
Digital Sync Gate
Not used for HDMI
Select buttons
H
Enables and disables the digital horizontal sync output.
V
Enables and disables the digital vertical sync output. To
use digital vertical sync, the digital separate H and V
sync must be selected.
C
Enables and disables the digital vertical sync output.
Digital Sync Polarity
Not used for HDMI
Select buttons
H
Determines whether the digital horizontal sync pulse
polarity is positive going or negative going.
V
Determines whether the digital vertical sync pulse polarity
is positive going or negative going.
C
Determines whether the digital composite sync pulse
polarity is positive going or negative going.
Video Gate
Select buttons
Enables you to gate ON or OFF any of the video
components. More than one can be selected.
R
Gates ON or OFF the Red component. Parameter:
REDG
G
Gates ON or OFF the Green component. Parameter:
GRNG.
B
Gates ON or OFF the Blue component. Parameter:
BLUG.
