980 DP Video Generator - User Guide Rev. A4
Page 25 July 14, 2014
Generator Status Area (Top)
The currently active format (selected resolution) and its directory path.
The currently active image (selected test pattern) and its directory path.
Video Identification Code (VIC)
The VIC code is shown on the lower left of the upper status panel
Resolution, scan and color
The resolution, scan and colorimetry type are shown on in the lower portion of the
upper status panel in the center.
The horizontal refresh rate of the selected timing.
The frame or vertical refresh rate of the selected timing.
The pixel clock rate of the selected timing.
Please note that if you are also making changes through the command line the information in the status area is
not automatically updated. You must click on the Refresh activation button to re-sync the status
area.
