5G Module Series
RM500Q-GL Hardware Design
RM500Q-GL_Hardware_Design 16 / 85
1.
1)
HPUE is only for single carrier.
2.
2)
Uplink 2 × 2 MIMO is only supported in 5G SA mode.
3.
3)
5G NR FDD bands only support 15 kHz SCS, and NR TDD bands only support 30 kHz SCS.
4.
4)
See document [2] for bandwidth supported by each frequency band in the NSA and SA modes.
5.
5)
The maximum rates are theoretical and for the actual values, refer to the network configuration.
6.
6)
To meet this operating temperature range, you need to ensure effective thermal dissipation, for
example, by adding passive or active heatsinks, heat pipes, vapor chambers, etc. Within this range,
the module can meet 3GPP specifications.
7.
7)
To meet this extended temperature range, you need to ensure effective thermal dissipation, for
example, by adding passive or active heatsinks, heat pipes, vapor chambers, etc. Within this range,
the module remains the ability to establish and maintain functions such as voice, SMS, emergency
call, etc., without any unrecoverable malfunction. Radio spectrum and radio network are not
influenced, while one or more specifications, such as P
out
, may undergo a reduction in value,
exceeding the specified tolerances of 3GPP. When the temperature returns to the normal operating
temperature level, the module will meet 3GPP specifications again.
Interfaces
AT Commands
Compliant with 3GPP TS 27.007 and 3GPP TS 27.005
Quectel enhanced AT commands
Internet Protocol
Features
Supports QMI/NTP* protocols
Supports the protocols PAP and CHAP usually used for PPP connections
Firmware Upgrade
USB 2.0 interface
PCIe interface
DFOTA
SMS
Text and PDU modes
Point-to-point MO and MT
SMS cell broadcast
SMS storage: ME by default
Physical
Characteristics
M.2 Key-B
Size: (30.0 ±0.15) mm × (52.0 ±0.15) mm × (2.3 ±0.2) mm
Weight: approx. 8.7 g
Temperature
Range
Operating temperature range: -30 °C to +70 °C
6)
Extended temperature range: -40 °C to +85 °C
7)
Storage temperature range: -40°C to +90°C
RoHS
All hardware components are fully compliant with EU RoHS directive
NOTES
