RM500Q-GL_Hardware_Design 70 / 85
6 Electrical Characteristics and
Reliability
6.1. Power Supply Requirements
The typical input voltage of RM500Q-GL is 3.7 V. The following table shows the power supply
requirements of RM500Q-GL.
Table 39: Power Supply Requirement
6.2. Current Consumption
Table 40: RM500Q-GL Current Consumption
Parameter
Description
Min.
Typ.
Max.
Unit
VCC
Power Supply
3.135
3.7
4.4
V
Voltage Ripple
-
30
100
mV
Voltage Drop
-
-
165
mV
Description
Conditions
Typ.
Unit
OFF state
Power down
71.8
μA
Sleep state
AT+CFUN=0 (USB disconnected)
4.615
mA
WCDMA PF = 64 (USB disconnected)
6.11
mA
LTE-FDD PF = 64 (USB disconnected)
6.98
mA
