Quectel 5G Series Hardware Design

5G Module Series
RM500Q-GL Hardware Design
RM500Q-GL_Hardware_Design 49 / 85
4.5. Control and Indication Interfaces
The following table shows the pin definition of control and indication pins.
Table 20: Pin Definition of Control and Indication Interfaces
4.5.1. W_DISABLE1#
RM500Q-GL provides a W_DISABLE1# pin to disable or enable airplane mode through hardware
operation. The W_DISABLE1# pin is pulled up by default. Driving it LOW will set the module to airplane
mode. In airplane mode, the RF function will be disabled.
The RF function can also be enabled or disabled through AT commands. The following table shows the
AT command and corresponding RF function status of the module.
Table 21: RF Function Status
Pin No.
Pin Name
I/O
Description
DC Characteristic
8
W_DISABLE1#
DI, OD
Airplane mode control.
Active LOW.
1.8/3.3 V
26
W_DISABLE2#
DI, OD
GNSS disable control.
Active LOW.
1.8/3.3 V
10
WWAN_LED#
DO, OD
Indicate RF status of the module.
Active LOW.
VCC
23
WAKE_ON_WAN#
DO, OD
Wake up the host.
Active LOW.
1.8/3.3 V
25
DPR*
DI, PU
Dynamic power reduction.
High voltage level by default.
1.8 V
38
SDX2AP_STATUS*
DO, PD
Status indication to AP
1.8 V
68
AP2SDX_STATUS*
DI, PD
Status indication from AP
1.8 V
W_DISABLE1# Logic Level
AT Commands
RF Function Status
High
AT+CFUN=1
Enabled
High
AT+CFUN=0
AT+CFUN=4
Disabled
