5G Module Series
RM500Q-GL Hardware Design
RM500Q-GL_Hardware_Design 20 / 85
5
GND
Ground
6
FULL_CARD_
POWER_OFF#
DI
Turn on/off of the
module.
High level: Turn on
Low level: Turn off
V
IH
max = 4.4 V
V
IH
min = 1.19 V
V
IL
max = 0.2 V
Internally pulled
down with a 100
kΩ resistor
7
USB_DP
AIO
USB 2.0 differential
data (+)
8
W_DISABLE1#
DI, OD
Airplane mode control.
Active LOW.
1.8/3.3 V
9
USB_DM
AIO
USB 2.0 differential
data (-)
10
WWAN_LED#
DO, OD
RF status indication
LED
Active LOW
11
GND
Ground
12
Notch
Notch
13
Notch
Notch
14
Notch
Notch
15
Notch
Notch
16
Notch
Notch
17
Notch
Notch
18
Notch
Notch
19
Notch
Notch
20
PCM_CLK
DIO, PD
PCM data bit clock
1.8 V
21
CONFIG_0
DO
Not connected
internally
22
PCM_DIN
DI
PCM data input
1.8 V
23
WAKE_ON_WAN#
DO, OD
Wake up the host.
Active LOW
1.8/3.3 V
24
PCM_DOUT
DO, PD
PCM data output
1.8 V
25
DPR*
DI, PU
Dynamic power
reduction.
High level by default
1.8 V
