Quectel EC25 User Manual

LTE Module Series
EC25&EC21 AT Commands Manual
EC25&EC21_AT_Commands_Manual 105 / 231
Example
AT+CRC=1 //Enable extended format
OK
+CRING: VOICE //Indicate incoming call to the TE
ATH
OK
AT+CRC=0 //Disable extended format
OK
RING //Indicate incoming call to the TE
ATH
OK
7.18. AT+CRLP Select Radio Link Protocol Parameter
The Write Command sets radio link protocol (RLP) parameters used when non-transparent data calls are
originated.
AT+CRLP Select Radio Link Protocol Parameter
Test Command
AT+CRLP=?
Response
TA returns values supported. RLP (Radio Link Protocol)
versions 0 and 1 share the same parameter set. TA returns
only one line for this set (where <ver> is not presented).
+CRLP:
(list of supported <iws>s),(list of supported <mws>s),(list of
supported <T1>s),(list of supported <N2>s),<ver>
+CRLP:
(list of supported <iws>s),(list of supported <mws>s),(list of
supported <T1>s),(list of supported <N2>s),<ver>
+CRLP:
(list of supported <iws>s),(list of supported <mws>s),(list of
supported <T1>s),(list of supported <N2>s),<ver>
OK
Read Command
AT+CRLP?
Response
TA returns current settings for RLP version. RLP versions 0
and 1 share the same parameter set. TA returns only one line
for this set (where <ver> is not presented).
+CRLP: <iws>,<mws>,<T1>,<N2>,<ver>
+CRLP: <iws>,<mws>,<T1>,<N2>,<ver>

Quectel EC25 Specifications

General

Category	LTE Module
LTE TDD	B38/B40/B41
WCDMA	B1/B5/B8
GSM	850/900/1800/1900 MHz
Data rates	LTE Cat 4: 150 Mbps DL/50 Mbps UL
GNSS	GPS/GLONASS/BeiDou/Galileo/QZSS
Operating Temperature	-40°C to +85°C
Form Factor	LCC
Storage Temperature	-45°C to +90°C
SIM Interface	1.8V/3.0V
Antenna Interface	Main, Diversity, GNSS
LTE FDD	B1/B3/B5/B7/B8/B20
Interfaces	USB 2.0, UART, PCM, GPIO
Operating Voltage	3.3V - 4.3V
Protocols	TCP/IP, UDP, FTP, HTTP, HTTPS
Certifications	CE, FCC, PTCRB, GCF, RCM, IC
