Page #210 background image
LTE Module Series
EC25&EC21 AT Commands Manual
EC25&EC21_AT_Commands_Manual 209 / 231
14.2. Factory Default Settings Restorable with AT&F
Table 8: Factory Default Settings Restorable with AT&F
GPRS
General Packet Radio Service
ME
Mobile Equipment
MS
Mobile Station
PDP
Packet Data Protocol
PSC
Primary Synchronization Code
RTS/CTS
Request To Send/Clear To Send
TA
Terminal Adapter
TCP
Transmission Control Protocol
TE
Terminal Equipment
UDP
User Datagram Protocol
UE
User Equipment
NV
Non-Volatile Random Access Memory
AT Command
Parameters
Factory Defaults
ATE
<value>
1
ATQ
<n>
0
ATS0
<n>
0
ATS3
<n>
13
ATS4
<n>
10
ATS5
<n>
8
ATS6
<n>
2
