Quectel EC25 User Manual

LTE Module Series
EC25&EC21 AT Commands Manual
EC25&EC21_AT_Commands_Manual 117 / 231
Example
AT+CSMS=? //Test command
+CSMS: (0,1)
OK
AT+CSMS=1 //Set type of message service as 1
+CSMS: 1,1,1
OK
AT+CSMS? //Read command
+CSMS: 1,1,1,1
OK
9.2. AT+CMGF Message Format
The command specifies the input and output format of the short messages. <mode> indicates the format
of messages used with Test, Read, Write and Execution Commands and unsolicited result codes resulting
from received messages.
The format of messages can be either PDU mode (entire TP data units used) or text mode (headers and
body of the messages given as separate parameters). Text mode uses the value of parameter <chset>
specified by AT+CSCS command to inform the character set to be used in the message body in the
TA-TE interface.
<service> setting 1 is mentioned under corresponding command
descriptions).
<mt> Mobile terminated messages
0 Type not supported
1 Type supported
<mo> Mobile originated messages
0 Type not supported
1 Type supported
<bm> Broadcast type messages
0 Type not supported
1 Type supported
AT+CMGF Message Format
Test Command
AT+CMGF=?
Response
+CMGF: (list of supported <mode>s)

Quectel EC25 Specifications

General

Category	LTE Module
LTE TDD	B38/B40/B41
WCDMA	B1/B5/B8
GSM	850/900/1800/1900 MHz
Data rates	LTE Cat 4: 150 Mbps DL/50 Mbps UL
GNSS	GPS/GLONASS/BeiDou/Galileo/QZSS
Operating Temperature	-40°C to +85°C
Form Factor	LCC
Storage Temperature	-45°C to +90°C
SIM Interface	1.8V/3.0V
Antenna Interface	Main, Diversity, GNSS
LTE FDD	B1/B3/B5/B7/B8/B20
Interfaces	USB 2.0, UART, PCM, GPIO
Operating Voltage	3.3V - 4.3V
Protocols	TCP/IP, UDP, FTP, HTTP, HTTPS
Certifications	CE, FCC, PTCRB, GCF, RCM, IC
