Quectel EC25 User Manual

LTE Module Series
EC25&EC21 AT Commands Manual
EC25&EC21_AT_Commands_Manual 146 / 231
10 Packet Domain Commands
10.1. AT+CGATT Attachment or Detachment of PS
The Write Command is used to attach the MT to, or detach the MT from the Packet Domain service. After
the command has been completed, the MT remains in V.25ter command state. If the MT is already in the
requested state, the command is ignored and the OK response will be returned. If the requested state
cannot be achieved, an ERROR or +CME ERROR response is returned.
Parameter
AT+CGATT Attachment or Detachment of PS
Test Command
AT+CGATT=?
Response
+CGATT: (list of supported <state>s)
OK
Read Command
AT+CGATT?
Response
+CGATT: <state>
OK
Write Command
AT+CGATT=<state>
Response
OK
If there is any error related to ME functionality:
+CME ERROR: <err>
Maximum Response Time
140s, determined by network.
Reference
3GPP TS 27.007
<state> Indicates the state of PS attachment
0 Detached
1 Attached
Other values are reserved and will result in an ERROR response to the Write Command

Quectel EC25 Specifications

General

Category	LTE Module
LTE TDD	B38/B40/B41
WCDMA	B1/B5/B8
GSM	850/900/1800/1900 MHz
Data rates	LTE Cat 4: 150 Mbps DL/50 Mbps UL
GNSS	GPS/GLONASS/BeiDou/Galileo/QZSS
Operating Temperature	-40°C to +85°C
Form Factor	LCC
Storage Temperature	-45°C to +90°C
SIM Interface	1.8V/3.0V
Antenna Interface	Main, Diversity, GNSS
LTE FDD	B1/B3/B5/B7/B8/B20
Interfaces	USB 2.0, UART, PCM, GPIO
Operating Voltage	3.3V - 4.3V
Protocols	TCP/IP, UDP, FTP, HTTP, HTTPS
Certifications	CE, FCC, PTCRB, GCF, RCM, IC
