EC25&EC21 AT Commands Manual
EC25&EC21_AT_Commands_Manual 207 / 231
13.5. AT+QSCLK Enable/Disable Entering into Sleep Mode
The command is used to control whether the module enters into sleep mode. When entering into sleep
mode is enabled, DTR is pulled up and WAKEUP_IN is pulled up, the module can directly enter into sleep
mode. If entering into sleep mode is enabled, DTR is pulled down and WAKEUP_IN is pulled down, there
is a need to pull the DTR pin and the WAKEUP_IN pin up first, and then the module can enter into sleep
mode.
Parameter
0 Fail
1 Success
<value> The voltage of specified ADC channel. Unit is mV.
AT+QSCLK Enable/Disable Entering into Sleep Mode
Test Command
AT+QSCLK=?
Response
+QSCLK: (list of supported <n>s)
OK
Read Command
AT+QSCLK?
Response
+QSCLK: <n>
OK
Write Command
AT+QSCLK=<n>
Response
OK
Maximum Response Time
300ms
Reference
Quectel
<n> 0 Disable slow clock
1 Enable slow clock. It is controlled by DTR

Quectel EC25 Specifications

General

Category	LTE Module
LTE TDD	B38/B40/B41
WCDMA	B1/B5/B8
GSM	850/900/1800/1900 MHz
Data rates	LTE Cat 4: 150 Mbps DL/50 Mbps UL
GNSS	GPS/GLONASS/BeiDou/Galileo/QZSS
Operating Temperature	-40°C to +85°C
Form Factor	LCC
Storage Temperature	-45°C to +90°C
SIM Interface	1.8V/3.0V
Antenna Interface	Main, Diversity, GNSS
LTE FDD	B1/B3/B5/B7/B8/B20
Interfaces	USB 2.0, UART, PCM, GPIO
Operating Voltage	3.3V - 4.3V
Protocols	TCP/IP, UDP, FTP, HTTP, HTTPS
Certifications	CE, FCC, PTCRB, GCF, RCM, IC
