Specifications
116 Kiaro! 50 User Guide
Label Specifications
Label
Rollstock 2.95” OD (75 mm) QuickLabel® paper
and synthetic labels
Label Size Width: 0.96” (24.4 mm) - 2.16” (55 mm)
Length: 1.0” (25.4 mm) - 15.63” (397
mm)
Construction Width (a): 1.12” - 2.48” (28.4 mm - 63
mm)
Edge Trim: (b) Left/Right: 0.157” (4.0
mm) - 0.276” (7.0mm)
Note: Matrix-in construction not allowed
Gap Length (c)
0.098” - 0.252” (2.5 mm - 6.4 mm)
0.250” - 0.375” (6.4 mm - 9.5 mm) with
reflective marks
Horizontal Position to Center (d)
9.5 mm, 3 mm dia.
