Kiaro! 50 Maintenance Utility
60 Kiaro! 50 User Guide
Setting the Vertical Baseline
The gap and reflective vertical baseline settings adjust the start of printing for gap or
reflective media. You can adjust the baseline -150 to +150 dots.
1 Launch the Kiaro! 50 Maintenance Utility.
From the Windows Start Menu, choose Start > All Programs > QuickLabel
Kiaro! 50 > Kiaro! 50 Maintenance Utility. A language and printer prompt will
open.
Select a display language and the Kiaro! 50 printer you want to connect to. Choose
OK.
2 Choose the Print Settings tab.
3 To read the vertical baseline values from the printer and set the Gap and
Reflective controls accordingly, choose Read From Printer.
4 Enter vertical baseline values for Gap and Reflective media.
In the following illustration, a label is exiting the printer. Note the positive and
negative adjustment directions.
5 To save the vertical baseline values, choose Save to Printer.
