Introduction
24 Kiaro! 50 User Guide
Internal View
Transport Unit
# Part Description
1 Maintenance Cartridge Ink used to clean the printhead is collected in this
cartridge.
# Part Description
1 Transport Unit Lever Open this lever to pull out the transport unit.
2 Transport Area This area transports media.
3 Media Alignment Line Align the leading edge of the media here.
[1]
[1]
[2]
[3]
[4]
[5]
[6]
