Designing and Printing Labels
52 Kiaro! 50 User Guide
13 Pass the media leading edge under the sensor (D), and align it with the media
alignment line (B).
Check that media does not float above the media guides (A and C). If it is hard to
feed media in, check whether the media guide is positioned properly.
If media has a large slack, take it up onto the media roll to remove the slack
appropriately. Media having a large slack may touch the media set lever, causing
the printer to malfunction.
Note: Ensure that the media guide (A) does not press the media and prevent
media movement.
14 While pressing on the top of the media guide (A), move the guide so it contacts the
edge of the media. When positioned correctly, the media guide (A) will prevent
side-to-side movement as media feeds through the printer.
Note: The guide should be positioned to just touch the edge of the media and not
cause media to curl on either side.
A
B
C
D
A
To Next Page
