System Overview
© Radiodetection 2016 5 RD1500 Operation Manual
Section 3 - System Overview
3.1 Introduction
This manual references embedded software version V1R1. To see which software version is
installed on your system, see Section 5.4 Swipe Down menu.
The RD1500 is a complete Ground Penetrating Radar system, offering two modes for acquiring
data: Line Scan and Grid Scan. Once the unit is assembled and powered-up, you can start
conducting a GPR survey in less than a minute.
Features of the RD1500 include:
 High visibility, touch screen display
 Display depth slices from collected grids, right in the field
 UWB Antenna producing high data quality
 FrequenSee™, which allows user to selectively view small, medium or large subsurface
targets
 Lightweight fibreglass cart frame
 Built-in WiFi capability
 Integrated GPS receiver with optional external GPS for increased positional accuracy for
geo-referencing data
 Ability to mark surface flags and subsurface interpretations
 Display your travelled path and targets in Map View
 Seamless export of data to EKKO_Project software for further data analysis
The RD1500 is also available in an Enhanced configuration. The chart below summarizes the
differences between the two configurations:
